PFO2910T Video Signal Optical Transmitter, 16 Channels #58170

Specifications

Interfaces: FC port (single-mode), 8×BNC, 2×RS485

Transmission distance: up to 20 km

Long wavelength: 1310 nm transmission, 1550 nm reception

Signal transmission distance: 1080p: 75-5 coaxial, 300 m

720p: 75-5 coaxial, 500 m

Input/output impedance: 75 Ohms

Sampling: 10 bit

General data

Power supply: 12 V DC

Power consumption: up to 24 W

Dimensions: 440×300×43.65 mm

Net weight: 3390 g

Rack-mountable

Operating conditions: -40 ºC… +70 ºC, relative humidity: 10% ~ 90%
